Belt Drive Model


Belt Drive Model

Features
    •    Suitable for straight line path or single Machine
    •     Modular Design
    •     Adjustable Blowing attachment
    •     Drive Mechanism by Pulleys and Belt arrangement
    •     Combination of PVC pipes, Rexine hoses and flexible hoses for Blowing and Suction arrangement
  2. Options
  3.         Automatic Parking Arrangement
  4.         Automatic Waste Collecting System
  5.         Intermittent Reversal System


Specification
Model NameMTB 200MTB 300
SystemBelt driveBelt drive
Fan Motor2 HP, 415v, 3Ø 50Hz, 2 Pole3 HP, 415v, 3Ø 50Hz, 2 Pole
Blowing Air Volume2100 m3/h2400 m3/h
Suction Capacity (Total Pressure)1900Pa2200Pa
No. of Blowing pipes x size *2 x 125 mm Dia2 x 125 mm Dia
No. of Suction pipes x size *4 x 100 mm Dia4 x 100 mm Dia
Travelling speed12/15 m/min12/15 m/min
Filter Area0.16 m20.16 m2
Travelling PathStraight lineStraight line





















    * Will vary according to the type of frames
